Specifications

• Engine & Transmission

  add remove
  • Engine Type:
    Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
  • Capacity:
    765 cc
  • Bore:
    3.1 in
  • Stroke:
    2.1 in
  • Compression:
    13.25:1
  • Max Power:
    95.6 kW / 12000 rpm
  • Max Torque:
    59.0 ft-lb / 9500 rpm
  • System:
    Multipoint sequential electronic fuel injection with electronic throttle control
  • Exhaust:
    Stainless steel 3 into 1 header system with low single sided stainless steel silencer
  • Final Drive:
    X-ring chain
  • Clutch:
    Wet, multi-plate, slip
  • Gearbox:
    6 speed
• Chassis

  add remove
  • Frame:
    Aluminium beam twin spar frame with 2 piece high pressure die cast rear subframe
  • Swingarm:
    Twin-sided, cast aluminium alloy
  • Front Wheel:
    Cast aluminium alloy 5 spoke, 17 x 3.5 in
  • Rear Wheel:
    Cast aluminium alloy 5 spoke, 17 x 5.5 in
  • Front Tyre:
    120/70 ZR 17
  • Rear Tyre:
    180/55 ZR 17
  • Front Suspension:
    Showa 41 mm upside down Big Piston Forks (BPF), adjustable compression and rebound damping, and preload adjustment. 115mm wheel travel
  • Rear Suspension:
    Öhlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping, and preload adjustment. 131.2mm wheel travel
  • Front Brake:
    Twin 310 mm floating discs, Brembo Stylema 4-piston radial monobloc calipers, OC-ABS, Brembo MCS radial master cylinder
  • Rear Brake:
    Single 220 mm disc, Brembo single piston caliper, OC-ABS
  • Instrument Display and Functions:
    Full colour 5" TFT instruments
• Dimensions & Weights

  add remove
  • Width Handlebars:
    31.2 in
  • Height Without Mirror:
    41.9 in
  • Seat Height:
    32.9 in
  • Wheelbase:
    55.1 in
  • Rake:
    23.2 º
  • Trail:
    3.8 in
  • Tank Capacity:
    4.0 gal
  • Wet Weight:
    414 lb
• Fuel Consumption

  add remove
  • CO₂ Figures:
    EPA Procedure CO2 emissions and fuel consumption data are measured according to regulation 40 CFR Part 86 Subpart F. Figures for fuel consumption are derived from specific test conditions and are for comparative purposes only. They may not reflect real dr
• Features

  add remove
  • Wheels and Tires:
    Pirelli Diablo Supercorsa V3 tires
  • Clutch:
    Slip & assist clutch
• Technology

  add remove
  • Riding modes:
    5 riding modes (Rain, Road, Sport, Track and Rider)
  • Instruments:
    5” TFT instruments
  • ABS:
    Optimized Cornering ABS
